| ART.EH1109 |
.jpg)
|
| Technical features: |
Suitable for domestic water services, heating and
air-conditioning plants, compressed air systems.
Minimum and maximum working temperature:
－10oC, 110oC.
Available: in all sizes from 1/8" up to 3/4". |
Materials:
|
|
Valve Body: C.P. Polished Brass
Handle: ABS
Ball: Hard chrome-plated brass
Seal: P.T.F.E.
Stem: Brass
Stem-seal: Brass
O-Ring: NBR
|
|
C.P forged mini ball valve
red handle; FxF
ISO228 thread
EH1107: red handle
EH1109: black handle
Size:1/8"~3/4"
|
.jpg) |
|
Size(mm)
|
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
| A |
36 |
39.5 |
40 |
46 |
54 |
| B |
5.5 |
8 |
8 |
9.5 |
13.5 |
| C |
22 |
22 |
22 |
22 |
22 |
| D |
19 |
21 |
21 |
25 |
30 |
| E |
26.5 |
28 |
28 |
29.5 |
32.5 |
|
|
