| ART.EH1260 |
|
| Technical features: |
|
Straight valve for thermostatic M30x1.5
Use: hot water
Maximum working pressure: 10bar
Maximum working temperature:110℃
Temperature：6℃~28℃
Pipe Thread to ISO7/1
|
Materials:
|
|
Valve Body: Brass
Head: ABS
Nut: Brass
Seal:EPDM
Stem: SS304
O-Ring: NBR or EPDM
|
|
Forged brass angle
thermostatic radiator
valve,with head
accord with EN215 standard
Size:1/2", 3/4"
|
 |
|
Size(mm)
|
1/2" |
3/4" |
| DN |
15 |
20 |
| B |
53 |
59 |
| H |
100 |
105 |
| C |
R1/2 |
R3/4 |
| D |
G1/2 |
G1/2 |
|
|
